ABAQUS Tutorial: Multiple Step Analysis in Abaqus

(1 customer review)

$ 65.00

In this training package, you will learn how to transfer the results of heat transfer analysis, such as thermal stress, from the Abaqus/ standard to impact analysis in Abaqus/explicit as an initial condition. You will learn the limitations, technical tips in modeling, as well as a practical example for low-velocity impact analysis on a composite plate.

Contents

  • Step-by-step training video which describes theories behind and how to model (*.mp4)
  • Abaqus files (*.cae, *.inp, *.jnl, *.odb)
  • Abaqus lecture notes (*.pdf)
  • Guarantee up to 3 month
Compare
Add to wishlist
Categories: , , Tags: , , , , , , , ,
Description
How to transfer results from Abaqus/Standard to Abaqus/Explicit?

ABAQUS Tutorial: Multiple Step Analysis in Abaqus

1- Transferring Results Between Abaqus/Explicit And Abaqus/Standard
1-1- Defining Initial Stresses Using Stress Output From A User-specified Output Database File
1-1-1- Importing Data From An Output Database File

The purpose of this video is to teach you how to apply thermal stresses resulting from heat transfer analysis of a composite material as an initial condition for dynamic explicit impact analysis.

What you learnā€¦

  • How to transfer analysis results from Abaqus/standard to Abaqus/explicit
  • How to do a sequentially coupled thermal-stress analysis in ABAQUS
  • How to define stress, strain, &, etc. as an initial condition in Abaqus
  • How to do multi-step analysis in Abaqus
  • How to define laminated composite materials
  • How to define initial condition by ODB file
  • how to perform heat transfer analysis
  • How to perform impact analysis
  • How to create rigid bodies
  • How to create *.res file

Package Uses

  • In analyzes such as fire analysis, it is necessary to use temperature and stress results in the next analysis as initial conditions.
  • Simulate a preloading phase where the capabilities of ABAQUS/Explicit are not needed (no contact, etc.).
  • Simulate further forming steps after an intermediary spring back phase.
  • Simulate a transient event after steady-state conditions have been found (e.g., with a steady-state transport simulation).
